002_CURVATURE BASED GRADIENT RIBS/APERTURES

This script takes in a set of curves, makes a surface, then uses isocurves of the surface to output a single closed mesh geometry with a gradient rib and aperture structure.

This excersice covers:

1- Surface construction from curves

2- List managemengt and customization of curve evaluation values.

3-Setting up a domain of values for displacing points relative to its base geometry

4- Understanding the relationship between points, lines, surfaces and meshes.

5- Using an attractor curve for splitting a set of geometry into two compartments.

6- Using Weaverbird plugin.

https://github.com/bits2atoms/002_CURVATURE-BASED-GRADIENT-RIBS.git
